黑光发生器电路BlackLight
黑光发生器电路BlackLightThiscircuitisasimpleultraviolatelightthatcanbepoweredbya6voltbatteryorpowersupplythatiscapableofsupplying1ormoreamps.
TheoriticalDiagramm
PARTSPartTotalQty.DescriptionC110.0047ufMonoCapacitorC210.1ufDiscCapacitorD1,D221N4007DiodeFTB1FilteredBlacklightTubeIC11555TimerICP1110kTrimPotQ11TIP30PNPPowerTransistorR11470OhmResistorR21270OhmResistorT11MediumYellowInverterTransformerMISC1ICSocket,HeatSinkForQ1,Screw,Nut,WireandPCBoard
黑光发生器电路BlackLig
